All-In-One Mono Laser Printer | Brother MFC-L5700DN

Overview

Business class 3 in 1 mono laser printer

Maximise Performance & Reduce Print Spend

First page out time is just 7.5 seconds followed by a fast print speed of up to 46ppm. Standard paper input is 570 expandable to 2,650. As well as improved performance, reducing print spend is something that every business looks at - with the optional 12,000 page super high yield toner your overall printing costs will reduce dramatically.

Close up of 3 in 1 printers with paper tray pulled out

Better reliability

Perform for longer, with a recommended monthly volume of up to 7,500 pages to meet the demands of the busy office. Plus, units have been totally remodelled with robust build quality that’s even more resilient and hardwearing.

Close up of 3 in 1 printer, with hand holding ID card

Tighter security

The MFC-L5700DN has the highest levels of security. Meeting requirements with secure function lock 3.0, Active directory connectivity and Internet Protocol Security (IPsec). Tap and print, your ID card or mobile phone using near-field communications(NFC), is also available for added security and convenience.

Women in green jacket sat on desk with professional 3 in 1 mono laser printer

Flexible print solutions from Brother

Brother print solutions are exciting packages of innovation designed to make doing business easier. By offering a range of print solutions to help your customers maximise print efficiency and minimise costs, we help you add value to every printer.

Specification Details

Features and Specifications

Printer Type	Mono
Functions	Print, Copy and Scan, Fax
Display	Colour touchscreen
Display size	9.3cm Colour touchscreen
Laser classification	Class 1 Laser Product (IEC 60825-1:2007)
Max paper size	A4
Memory	256MB
Processor	Cortex-A9 800MHz
Technology	Laser

Connectivity	Wired Network,
Local interface	Hi-Speed USB 2.0 & USB Host for direct print and scan from a USB Flash Drive
Wired network interface	Ethernet (10Base-T/100Base-TX)

Supported	AirPrint, Android Print Service Plugin, Cortado Cloud Print™, Google Cloud Print 2.0, iPrint&Scan, Mopria

Resolution	Up to 1200 x 600 dpi

With carton	20.1 kg
Weight	16.5 kg
With carton	545(w) x 520(d) x 641(h) mm
Without carton	435(w) x 427(d) x 486(h) mm

Sound power	Printing 6.67BA, Quiet mode printing 6.47BA, Ready mode up to 4.80BA
Sound pressure	Printing 54dBA, Quiet Mode printing 52dBA, Ready mode up to 35dBA
Blue Angel environmental accreditation	Yes
Nordic Swan environmental accreditation	Yes
Typical electrical consumption	0.556KWh / Week

Fax modem	33.6 Kb per second
Internet fax	Yes (Available as a download from support.brother.com)
PC Fax	Send and Receive

Contents	Fax line cord, Power supply cord, Product safety guide, Software disc, Supplies, User guide, Warranty card, Quick setup guide

Types and sizes	Standard & Optional Trays – plain, recycled, coloured and letterhead paper (between 60 - 120gsm). Multi Purpose Tray - plain, recycled, bond, coloured and letterhead paper (between 60 - 200gsm). 2-sided Print - plain, recycled, coloured and letterhead paper (between 60 - 105gsm)
Weights	Standard Tray - A4, Letter, A5, A5(Long Edge), A6, Executive, Legal, Folio, Mexico Legal, India Legal. Optional Tray - A4, Letter, A5, Executive, Legal, Folio, Mexico Legal, India Legal. Multi Purpose (MP) Tray - Width: 76.2mm to 215.9mm x Length: 127mm to 355.6mm. 2-sided Print – A4. Automatic Document Feeder (ADF) - Width: 105mm to 215.9mm x Length: 147.3mm to 355.6mm

Wired network security	APOP, SMTP-AUTH, SSL/TLS (IPPS, HTTPS, SMTP, POP3, IMAP4), SNMP v3, Kerberos, IPSec, 802.1x (EAP-MD5, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS) When Internet FAX has been downloaded.

Supported	Windows®: Windows 10® (32 & 64 bit editions), Windows 8® (32 & 64 bit editions),Windows 7® (32 & 64 bit editions), Windows Vista® (32 & 64 bit editions), Windows® XP Professional (32 & 64 bit editions), Windows® XP Home Edition, Windows® Server 2012, Windows® Server 2008R2, Windows® Server 2008 (32 & 64 bit editions), Windows® Server 2003 (32 & 64 bit editions). Note that Windows® Server supports network printing only. / Mac: OS X 10.8.5, 10.9.x, 10.10.x, 10.11.x or greater / Linux CUPS, LPD/LPRng (x86/x64 environment)

Supported

Windows®: Windows 10® (32 & 64 bit editions), Windows 8® (32 & 64 bit editions),Windows 7® (32 & 64 bit editions), Windows Vista® (32 & 64 bit editions), Windows® XP Professional (32 & 64 bit editions), Windows® XP Home Edition, Windows® Server 2012, Windows® Server 2008R2, Windows® Server 2008 (32 & 64 bit editions), Windows® Server 2003 (32 & 64 bit editions). Note that Windows® Server supports network printing only. / Mac: OS X 10.8.5, 10.9.x, 10.10.x, 10.11.x or greater / Linux CUPS, LPD/LPRng (x86/x64 environment)

Paper Input	Lower Tray – 250 sheets, Multi Purpose Tray – 50 sheets, Automatic Document Feeder (ADF) – 50 sheets
Paper Output	Face Down - 150 sheets, Face Up (Straight Paper Path) - 1 sheet

A4 2-sided print speed	20
A4 standard print speed	40
Resolution	Up to 1,200 x 1,200dpi
Automatic 2 sided print	Yes
Emulations	PCL6, BR-Script3 (Postscript®3™ Language Emulation), IBM Proprinter XL, Epson FX-850, PDF Version 1.7, XPS Version 1.0
First print out time	7.2 seconds
Recommended monthly volume	Up to 3,500 pages

Resolution	Up to 1,200 x 1,200dpi (from flatbed), 600 x 600dpi (from ADF), 19,200 x 19,200dpi (Enhanced)
Speed	Mono: 24ipm, Colour: 20ipm
Scanner type	CIS

802.1x	Yes
IP filter	Yes
Secure function lock v3	Yes
Secure print	Yes
Secure printing with SSL	Yes

Supported	AirPrint, Android Print Service Plugin, Box, Brother Apps, BSI, Cortado Cloud Print, Dropbox, Evernote, Google Cloud Print 2.0, Google Drive, iPrint&Scan, ISIS, Managed Print Services, Mopria, OneDrive, OneNote, PrintSmart Solutions

Accessories	Optional Lower Tray LT-5500 - Up to 250 sheets, Optional Lower Tray LT-6500 - Up to 520 sheets, Filter Holder FH-1000 (Germany only)
Supplies	Inbox Toner Approx. 2,000 pages, Standard Toner TN-3430 - Approx. 3,000 pages, High Yield Toner TN-3480 - Approx. 8,000 pages, Drum DR-3400 - Approx. 50,000 A4 pages (3 pages per job) / 30,000 A4 pages (1 page per job)
