MFC-L5750DW

The professional all-in-one performer is here

Super-fast print speeds of up to 40ppm and scan speeds of up to 48ipm

Combined paper input of 300 sheets

Automatic 2-sided printing

Product Overview

MFCL5750DW

High-Yield Replacement Cartridges - Optional high yield 8,000 page toner cartridge

Intuitive 12.3cm touchscreen LCD display

High speed wired (10Base-T/100 Base-TX) and wireless (IEEE 802.11b/g/n) network interfaces plus USB 2.0 connectivity and Wi-Fi Direct

Key Features

  • Super-fast print speeds of up to 40ppm and scan speeds of up to 48ipm
  • Combined paper input of 300 sheets
  • Automatic 2-sided printing
  • High-Yield Replacement Cartridges - Optional high yield 8,000 page toner cartridge
  • Intuitive 12.3cm touchscreen LCD display
  • High speed wired (10Base-T/100 Base-TX) and wireless (IEEE 802.11b/g/n) network interfaces plus USB 2.0 connectivity and Wi-Fi Direct

About this product:

Print, scan, copy and fax more efficiently with the MFC-L5750DW. With fast operating speeds and a large, user-friendly 12.3cm touchscreen display, this all-in-one mono laser device boasts optimum productivity and versatility to meet the needs of the most demanding business environment.

At a glance

  • Blue Angel logo

Specifications

General

Printer Type Mono
Functions Print, Copy and Scan, Fax
Display Colour touchscreen
Display size 12.3cm Colour touchscreen
Laser classification Class 1 Laser Product (IEC 60825-1:2007)
Max paper size A4
Memory 256MB
Processor Cortex-A9 800MHz
Technology Laser

Connectivity

Connectivity Wired Network, Wireless,
Local interface Hi-Speed USB 2.0 & USB Host for direct print and scan from a USB Flash Drive
Wirelesss network interface IEEE 802.11b/g/n
Wired network interface Ethernet (10Base-T/100Base-TX)

Mobile Connectivity

Supported AirPrint, Android Print Service Plugin, Cortado Cloud Print™, Google Cloud Print 2.0, iPrint&Scan, Mopria, Wi-Fi Direct™

Copying

2-sided copy Yes
Resolution Up to 1200 x 600 dpi

Dimensions & weights

With carton 20.2 kg
Weight 16.5 kg
With carton 545(w) x 520(d) x 641(h) mm
Without carton 435(w) x 427(d) x 486(h) mm

Environment accreditation

Sound power Printing 6.67BA, Quiet mode printing 6.47BA, Ready mode up to 4.80BA
Sound pressure Printing 54dBA, Quiet Mode printing 52dBA, Ready mode up to 35dBA
Blue Angel environmental accreditation Yes
Nordic Swan environmental accreditation Yes
Typical electrical consumption 0.556KWh / Week

Faxing

Automatic 2 sided faxing Yes
Fax modem 33.6 Kb per second
Internet fax Yes (Available as a download from support.brother.com)
PC Fax Send and Receive

In the Box

Contents Fax line cord, Power supply cord, Product safety guide, Software disc, Supplies, User guide, Warranty card, Quick setup guide

Media specifications

Types and sizes Standard & Optional Trays – plain, recycled, coloured and letterhead paper (between 60 - 120gsm). Multi Purpose Tray - plain, recycled, bond, coloured and letterhead paper (between 60 - 200gsm). 2-sided Print - plain, recycled, coloured and letterhead paper (between 60 - 105gsm)
Weights Standard Tray - A4, Letter, A5, A5(Long Edge), A6, Executive, Legal, Folio, Mexico Legal, India Legal. Optional Tray - A4, Letter, A5, Executive, Legal, Folio, Mexico Legal, India Legal. Multi Purpose (MP) Tray - Width: 76.2mm to 215.9mm x Length: 127mm to 355.6mm. 2-sided Print – A4. Automatic Document Feeder (ADF) - Width: 105mm to 215.9mm x Length: 147.3mm to 355.6mm

Network

Wired network security APOP*, SMTP-AUTH, SSL/TLS (IPPS, HTTPS, SMTP, POP3*, IMAP4*), SNMP v3, Kerberos, IPSec, 802.1x (EAP-MD5, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS) *When Internet FAX has been downloaded.
Wireless network security WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (AES), APOP*, SMTP-AUTH, SSL/TLS (IPPS, HTTPS, SMTP, POP3*, IMAP4*), SNMP v3, Kerberos, IPSec, 802.1x (LEAP, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS) *When Internet FAX has been downloaded.

Operating systems

Supported Windows®: Windows 10® (32 & 64 bit editions), Windows 8® (32 & 64 bit editions),Windows 7® (32 & 64 bit editions), Windows Vista® (32 & 64 bit editions), Windows® XP Professional (32 & 64 bit editions), Windows® XP Home Edition, Windows® Server 2012, Windows® Server 2008R2, Windows® Server 2008 (32 & 64 bit editions), Windows® Server 2003 (32 & 64 bit editions). Note that Windows® Server supports network printing only. / Mac: OS X 10.8.5, 10.9.x, 10.10.x, 10.11.x or greater / Linux CUPS, LPD/LPRng (x86/x64 environment)

Paper handing

Paper Input Lower Tray – 250 sheets, Multi Purpose Tray – 50 sheets, Automatic Document Feeder (ADF) – 50 sheets
Paper Output Face Down - 150 sheets, Face Up (Straight Paper Path) - 1 sheet

Printing

A4 2-sided print speed 20
A4 standard print speed 40
Resolution Up to 1,200 x 1,200dpi
Automatic 2 sided print Yes
Emulations PCL6, BR-Script3 (Postscript®3™ Language Emulation), IBM Proprinter XL, Epson FX-850, PDF Version 1.7, XPS Version 1.0
First print out time 7.2 seconds
Recommended monthly volume Up to 3,500 pages

Scanning

2-Sided scan Yes
Resolution Up to 1,200 x 1,200dpi (from flatbed), 600 x 600dpi (from ADF), 19,200 x 19,200dpi (Enhanced)
Speed Standard mono: 24ipm / 2-Sided mono: 48ipm, Standard colour: 20ipm / 2-Sided colour: 34ipm
Scanner type

Security features

802.1x Yes
IP filter Yes
Secure function lock v3 Yes
Secure print Yes
Secure printing with SSL Yes

Solutions

Supported AirPrint, Android Print Service Plugin, Box, Brother Apps, BSI, Cortado Cloud Print, Dropbox, Evernote, Google Cloud Print 2.0, Google Drive, iPrint&Scan, ISIS, Managed Print Services, Mopria, OneDrive, OneNote, PrintSmart Solutions

Supplies and accessories

Accessories Optional Lower Tray LT-5500 - Up to 250 sheets, Optional Lower Tray LT-6500 - Up to 520 sheets, Filter Holder FH-1000 (Germany only)
Supplies Inbox Toner Approx. 2,000 pages, Standard Toner TN-3430 - Approx. 3,000 pages, High Yield Toner TN-3480 - Approx. 8,000 pages, Drum DR-3400 - Approx. 50,000 A4 pages (3 pages per job) / 30,000 A4 pages (1 page per job)

Warranty

Warranty Two Year Manufacturer's Warranty (Year 1 on-site, Year 2 Back to base)
